Quick Pipeline repairer
Pipe repair clamp is a kind of equipment for pipeline repair.it is essentially a pre-rolled band of stainless steel that is lined with rubber inside. To repair a pipe, the repair clamp is simply placed over the area that is leaking and then tightened with the bolts and nuts to compress the interior rubber seal ring，The tensile force applied by the clamp fasteners is converted to a radial pressure on the rubber seal ring,so as to form a seal around the leak
Structure of repair clamp:
1. Shell: Made of stainless steel 304/316
2. Sealing ring:
(1) EPDM material.Applicable temperature ranging from: -30 ℃~+130 ℃Applicable media: Can be used for water, wastewater, air, solids, chemicals,etc
(2) NBR material:Applicable temperatures ranging from -25 ℃ to+100 ℃Applicable media: can be used for natural gas, oil, fuel, and various hydrocarbons,etc
(3) Also Optional about sealing ring: HNBR,MVQ,FPM
3. Fasteners:Anti corrosion Dacromet treated heavy-duty bolts, shaft pins, or optional stainless steel accessories
